The SE50 V vibratory screed is equipped with rear-mounted extenders and vibratory screed plates. It offers a paving range of 2.55 m - 6.5 m (8' 4" - 21' 4") and excels on highways, parking lots, urban streets and other variable width paving applications.
Standard Weight 7239 lb
Standard Paving Range 2.55 - 5.0 m (8' 4" - 16' 4")
Maximum Paving Width 21.3 ft
Vibratory Speed Range 0 to 3000 vpm
Standard Weight 7239lb
Crown Range -4% to +10%
Extender Height Range -20 mm to +50 mm
Extender Slope Range -3% to +10%
Heating Time - Maximum Width 25 minutes
Heating Time - Standard Width 15 minutes
Maximum Paving Depth 12in
Maximum Paving Width 21.3ft
Standard Paving Range 2.55 - 5.0 m (8' 4" - 16' 4")
Vibratory Speed Range 0 to 3000 vpm
Length - Front to Back, Endgates Attached 92in
Length - Front to Back, Endgates Removed 68in
Screed Plate Width - Front to Back 16in
Transport Length - Tractor and Screed 22.1ft
Transport Width - Endgates Folded 8.3ft
