Continuous Rating 1840 ekW @1.0pf
Fuel Type Natural Gas, Biogas, Coal Gas, Hydrogen Blend (up to 25%)
Maximum Electrical Efficiency 44.70%
Maximum Standby Rating 1840
Continuous Rating 1840 ekW @1.0pf
Frequency 50 Hz
Fuel Type Natural Gas, Biogas, Coal Gas, Hydrogen Blend (up to 25%)
Maximum Electrical Efficiency 44.70%
Maximum Standby Rating 1840
RPM 1500 rpm
Aspiration TA
Bore 6.7in
Engine Model CG170B-16
Stroke 7.7in
Dry Weight - Genset 38360lb
Height 86in
Length 240in
Width 67in
Turbocharger with a water-cooled bearing case for all cylinder
One-element single-stage air cleaner with enclosure and sevice indicator
TPEM (Total Plant & Energy Management System)
flange connections for JW inlet and outlet
Electrical jacket water and aftercooler coolant pump
Jacket water and SCAC thermostats
ANSI/DN customer flange connections for JW inlet and outlet
PEARL/Low resistence exhaust system
Exhaust waste gate for the CG170B-16
Closed crankcase ventilation system
Electronic fuel metering valve
Independently controlled cylinder monitoring and ignition system
Pre-chamber spark plugs
closed-coupled generator result in no torque transmission to the base frame
Winding temperature detectors
Busbar connections
3-phase sensing and KVAR/PF control
grid code generator
Reactive droop
Anti-condensation space heater
24V starting motors
Battery disconnect switch
Crankshaft vibration damper and guard
CHP skid
50Hz: Germany, Belgium, Great Britain, Italy, Poland, and Netherlands
