Cat® Hammers for Skid Steer Loaders, Compact Track Loaders, Mini Excavators and Backhoe Loaders are high performance breakers, designed for maximum performance on demolition, construction, and road work.
Operating Weight - With Tool 162.3 lb
Energy Class 147.5 ft·lbf
Machine Class 300.9D Mini Excavator
Tool Shaft Diameter 1.6 in
Energy Class 147.5ft·lbf
Height - Without Tool 29.4in
Impact Frequency 800-1400 bpm
Machine Class 300.9D Mini Excavator
Minimum Carrier Weight 1979.7lb
Minimum Operating Pressure 1276psi
Mounting Bracket Size Pin On
Operating Weight - With Tool 162.3lb
Optimal Hydraulic Flow 15-25 lpm (4-6.6 gpm)
Overall Height 37.7in
Overall Length 8.2in
Overall Width 7.8in
Sound Level 122 dB
Tool Shaft Diameter 1.6in
