Cat® Hammers for Skid Steer Loaders, Compact Track Loaders, Mini Excavators and Backhoe Loaders are high performance breakers, designed for maximum performance on demolition, construction, and road work.
Operating Weight - With Tool 1382.3 lb
Energy Class 1500.2 ft·lbf
Machine Class 7-10 Ton Mini Excavators, 415-450 Backhoe Loaders (No Side Shift)
Tool Shaft Diameter 3.4 in
Energy Class 1500.2ft·lbf
Height - Without Tool 49.2in
Impact Frequency 700-1260 bpm
Machine Class 7-10 Ton Mini Excavators, 415-450 Backhoe Loaders (No Side Shift)
Minimum Carrier Weight 15399.3lb
Minimum Operating Pressure 1450.4psi
Mounting Bracket Size Extra Large
Operating Weight - With Tool 1382.3lb
Optimal Hydraulic Flow 70-150 lpm (18-40 gpm)
Overall Height 65.6in
Overall Length 20.5in
Overall Width 20.2in
Sound Level 124 dB
Tool Shaft Diameter 3.4in
