Cat® Snow Wings are designed with versatility in mind. With independently controlled wings and angling capability, the attachment can be configured to suit the needs of any job and continue to adapt to ever changing needs by being able to hydraulically configure for plowing, pushing, and backdraging to enable cleaning and maintaining roadways, sidewalks and other passages for safe passage in winter conditions.
Working Width (Wings Closed) 96.5 in
Overall Width (Wings Closed) 104.2 in
Overall Width (Wings Open) 161.7 in
Working Width (Wings Open) 161.7 in
Float ±5 Degrees
Hydraulic Angling - Left/Right of Center ±35 Degrees
Interface Type Skid Steer Coupler
Length 67.1in
Optimal Hydraulic Flow 76-87 L/min (20-23 gpm)
Optimal Hydraulic Pressure 200-230 bar (2800-3300 psi)
Overall Height 36in
Overall Width (Wings Closed) 104.2in
Overall Width (Wings Open) 161.7in
Required Hydraulics Standard Flow w/14 pin Electrical
Trip Edge Height 5.1in
Trip Edge Quantity 1
Trip Edge Type Steel
Weight 1911.4lb
Wing Rotation 180 Degrees
Working Width (Wings Closed) 96.5in
Working Width (Wings Open) 161.7in
