Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
Standby Rating 60 ekW
Frequency 60 Hz
Emissions/Fuel Strategy U.S. EPA Tier 3 Certified
Voltage 208 to 600 Volts
Duty Cycle Standby
Emissions/Fuel Strategy U.S. EPA Tier 3 Certified
Frequency 60 Hz
Speed 1800 rpm
Standby Rating 60 ekW
Voltage 208 to 600 Volts
Aspiration Turbocharged
Bore 4.1in
Compression Ratio 16.7:1
Displacement 269in
Engine Model C4.4, In-line 4, 4-cycle diesel
Fuel System Electronic (adjustable)
Governor Type Mechanical, ADEM™A4
Stroke 5in
Dry Weight - Genset (maximum) 2054lb
Height - Maximum 48in
Length - Maximum 77.2in
Width - Maximum 43.3in
Standard air cleaner
Power terminal strip
GCCP 1.2 Control panel
Wide base
Coolant drain line with valve
Fan drive, battery charging alternator drive
Caterpillar extended life coolant
Radiator and cooling fan with guards
Radiator stone guard
NFPA110 bundle
Ground fault relay
Remote E-stop button
Remote annunciator module
Audible alarm
I/O module
Electronic governor
Oil drain line with valve
Lubricating oil
Engine and alternator pre-paint, Caterpillar yellow
Standard batteries
Cat® Product Link™ PL444 cellular
IBC seismic
NFPA battery charger
Single / Multi manual
Second circuit breaker box
Power terminal strip
Ground fault relay
Remote E-stop button
Oil temperature gauge and sender
Audible alarm
Remote annunciator module
External emergency stop / DC Lighting
Sound attenuated Level 2
10, 25 and 35 dBA silencer systems
Overhead silencer mounting kit
Emergency vent pipe
Base integral 24 hrs
Jacket water heater
Coolant heater
Anti-condensation heater
Lube oil sump heater
Permanent magnet excitation (PMG) generator
Cat Alternator
Seismic vibration isolators
