Rating Prime 20 kVA
Frequency 50 Hz
Voltage 220 - 415 V
Fuel/Emissions Strategy EU Stage V
Frequency 50 Hz
Fuel/Emissions Strategy EU Stage V
Rating Prime 20 kVA
Voltage 220 - 415 V
Emissions EU Stage V
Engine Cat® C2.2
Fuel Diesel
Height 50.1in
Length 67.1in
Weight - With Lube Oil and Coolant 1793lb
Width 39.1in
100% Load 50 Hz 1.45gal/hr
75% Load 50 Hz 1.05gal/hr
Sound Power @ 1 meters (3 feet) @ 75% of rating (50Hz) 65 dB(A)
Naturally aspirated
Mechanical Governor
LC1100 Frame
Coastal insulation protection
GCCP 1.3 set mounted digital controller
Air cleaner, cyclonic/paper with dust cup and serviceindicator
Provides package monitoring and management
Package mounted radiator with vertical air discharge. Filled from factory
High ambient performance
12V, heavy duty charging alternator with integral regulator and belt guards
12 hour dual wall fuel tank with internal fuel fill
Engine mounted primary and secondary fuel filter
Separate robust steel enclosures for control & distribution sections
4 pole, 40A main circuit breaker
Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance
Sealed quarter-turn compression latches with key or padlock capabilities
On engine primary and secondary oil filters. Filled from factory
Factory tested and inspected
Full manufacturer's warranty
CE socket box with integrated MCB & RCBO protection
Inboard mounted 3-way valve for external fuel connection, electronic fuel gauge and Bund Level Sender
Oil and coolant drains piped to base frame
