Cat® Augers are used for drilling holes for footings, fencing, signs, trees and shrubs in construction, agricultural, and landscaping applications. They are designed with the right amount of speed and torque for maximum productivity in a broad range of soil types.
Drive Shaft Torque at Maximum Pressure 5037.5 lb/ft
Drive Method Gerotor Motor - Double Planetary Reduction
Mounting Bracket Design 415-444 Backhoe Loader Pin On
Required Hydraulics High Flow XPS
Bit Speed at Maximum Flow 81 rpm
Drive Method Gerotor Motor - Double Planetary Reduction
Drive Shaft Torque at Maximum Pressure 5037.5lb/ft
Hex Output Shaft Size 2in
Housing Diameter 11in
Motor Displacement 2.67in³
Mounting Bracket Design 415-444 Backhoe Loader Pin On
Optimal Hydraulic Flow 95-130 L/min (25-34 gpm)
Optimal Hydraulic Pressure 207-290 bar (3002-4206 psi)
Overall Height 39.6in
Overall Length - With Bracket 25.6in
Overall Width - With Bracket 14.1in
Required Hydraulics High Flow XPS
Swing Range (L/R) 76 degrees
Swing Range (fore/aft) 117 degrees
Weight 403.4lb
