CC2.7 Utility Compactor

CC2.7 Utility Compactor

The CC2.7 is a 3 metric ton machine with a 1200 mm (47 in) front drum and 4 rear wheels. The combination compactor offers versatility with its 4 rubber tires that provide a kneading action for a smooth mat surface.

  • Standard Operating Weight with ROPS 5718 lb

  • Compaction Width 47.2 in

  • Gross Power 48.2 hp

  • Static Linear Load 61 lb/in

Request a quote

Product Specifications

Specifications

Weights

  • Maximum Operating Weight 6114lb

  • Standard Operating Weight with ROPS 5718lb

  • Static Linear Load 61lb/in

Dimensions

  • Compaction Width 47.2in

  • Drum Diameter 28.3in

  • Drum Width 47.2in

  • Height - ROPS 109.7in

  • Overall Length 99.2in

  • Overall Width 51.7in

  • Wheel Base 70.9in

Engine

  • Engine Model C1.7T

  • Gross Power 48.2hp

  • Net Power - ISO 9249 48.2hp

Operating Specifications

  • Curb Clearance 17.8in

  • Drum Offset 2in

  • Ground Clearance 11.2in

  • Number of Wheels 4

  • Static Linear Load 66.2lb/in

  • Travel Speed - Maximum 6.8mile/h

  • Turning Radius - Inside Drum Edge 100in

  • Turning Radius - Outside Drum Edge 147.2in

Vibratory System

  • Centrifugal Force per Drum - Maximum 7929lb/ft

  • Maximum Frequency 3840VPM

  • Minimum Frequency 3180VPM

  • Nominal Amplitude - High 0.02in

Service Refill Capacities

  • Fuel Tank Capacity 14.37Gal

  • Water Spray Tank Capacity 42.24gal (US)

Features

Equipment

Standard Equipment

  • Adjustable Suspension Seat with Operator Presense Switch

  • ROPS Folding

  • Seat Belt - 75 mm (3 in) high visibility orange

  • Operator Console w/ Water Tank Gauge, Emergency Stop, and Glove Box

  • 12-volt Power Outlet

  • Horn, Backup Alarm

  • Folding Scrapers

  • Vibe Selection - front, rear, or both

  • Pressurized, Triple-Filtration Spray System with Test Mode

  • Auto Engine Off and Auto Warmup

  • Air Cleaner, Dual Element

  • Engine Belt Guard

  • Telematics

  • LED Working Lights

  • Vandal Protection - lockable hood, fuel fill, and controls cover

  • Machine Life and Tiedowns

  • Offsets Hitch

Optional Equipment

  • ROPS Fixed

  • Sun Canopy

  • Seat - Side Shift

  • Dual Propel Levers

  • Fixed Scrapers

  • Cocoa Mats

  • Edge Cutter Ready

  • Water Sprayer Antifreeze Kit

  • Ballast Kit - 100 kg (220 lb)

  • Remote Flash / Troubleshoot

  • CMV - Compaction Measurement Value

  • Battery Disconnect

  • LED Roading Lights

  • Rotating Amber Beacon

  • Biodegradeable Hydraulic Oil

  • Bumpers

  • Single Point Lift

  • Custom Paint
